    Api Oilfield Stage Collar For Cementing With A Diameter Of 6 5/8 Hydraulic Type Dv Tool

    Casing Stage Collar
    Stage collar is a mechanical tool used to complete the cementing operation into two times. Stage collar mainly consists of
    two-stage coupling (body), first-stage plug, baffle plate, free fall opening plug (it is used when you use the non-continuous
    process) or pump-down opening plug (it is used when you use the continuous process), closing plug
    1. It uses out-closing structure and locking device on the closing sleeve. The lock is reliable after the closing.
    2. The liquid would not occur in the loculum when opening or closing.
    3. The I.D. of upper/lower sub should be the same as that of casing, it can protect the body of stage collar from damaging when
    the bits going down and doing drill-out operation.
    4. All the accessories are made of drillable rubber or aluminum material. They have the function of anti-rotation, and can make
    the drill out easy.
    5. You can use the pumping-down plug to carry out continuous process.
    PRODUCT SPECIFICATIONS
    Specifications, (in)
    5 1/2"
    7"
    9-5/8"
    13 3/8"
    Max O.D., mm
    Φ170
    Φ208
    Φ283
    Φ381
    Drill-out I.D., mm
    Φ122
    Φ155
    Φ220
    Φ315
    Overall Length, mm
    1082
    1182
    1222
    1280
    Rated Load, t
    140
    170
    210
    300
    Sealing capacity, MPa
    25
    25
    25
    25
    Opening Pressure, MPa
    13
    13
    13
    14
    Closing Pressure, MPa
    5
    5
    5
    5
    Lower Sliding Sleeve I.D., mm
    Φ85
    Φ115
    Φ176
    Φ203
    Upper Sliding Sleeve I.D., mm
    Φ95
    Φ125
    Φ197
    Φ285


    Company Information

    Puyang Zhongshi Group Co., Ltd is a professional manufacturer of various oilfield equipments and cementing accessories since 1997, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.

    We have the certificates of API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001 and ISO 14001. Our foreign customers are mainly from America, Central Asia, Russia, Southeast Asia, Middle East, etc.
