API 11B Full Bodied Coupling Sucker Rod Centralizer / Oil Tubing Centralizer

Puyang Zhongshi Group Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap API 11B Full Bodied Coupling Sucker Rod Centralizer / Oil Tubing Centralizer from wholesalers

    Buy cheap API 11B Full Bodied Coupling Sucker Rod Centralizer / Oil Tubing Centralizer from wholesalers
    • Buy cheap API 11B Full Bodied Coupling Sucker Rod Centralizer / Oil Tubing Centralizer from wholesalers

    API 11B Full Bodied Coupling Sucker Rod Centralizer / Oil Tubing Centralizer

    Ask Lasest Price
    Brand Name : ZS
    Model Number : 5/8'' 3/4'' 7/8'' 1'' 1-1/8''
    Certification : API
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000sets/month
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    API 11B Full Bodied Coupling Sucker Rod Centralizer / Oil Tubing Centralizer

    The sucker rod centralizers are used to protect sucker rod to reduce wearing.

    Feature of rod centralizer

    1) Standard: API 11B

    2) API and ISO certified

    3) Specification: 16mm, 19mm, 22mm, 25mm, 28mm

    4) Type: Coupling Rod Guide, Wheeled Rod Guide, Clamp Rod Guide

    Description of rod centralizer

    Sucker Rod Guide, or Sucker Rod Centralizer, used in pumping well, is a tool which can set upright the sucker rod, and protect the sucker rod from wiping with tubing pipe.

    4.Application

    CASING SIZE TUBING CENTRALIZER TUBING CENTRALIZER
    NO. OCTG ERW (ID) (OD)
    1 5.5" 2-3/8"(60.325mm) 110mm
    2 7" 6" 2-3/8"(60.325mm) 140mm
    3 7" 6" 2-7/8"(73.025mm) 140mm
    4 2-7/8"(73.025mm) 114-115mm
    5 7" 3-1/2"(88.900mm) 140mm
    6 0.83"(210.82mm) 419.1mm
    7 1.19"(302.26mm) 419.1mm
    Remark

    Rod centralizers with full-bore-fluted centralizers should be placed on or between the pump-handling pony rod, the sinker bars used above the pump, and the first two sucker rods above the sinker bars. Rod centralizers in these locations help stabilize the pump and valve rod and prevent valve-rod bending or breakage. When a tubing anchor is not used, rod centralizers will reduce tubing wear because of tubing helical buckling on the upstroke. Rod centralizers also may be used in crooked holes in which there are areas of concentrated tubing wear.

    Quality API 11B Full Bodied Coupling Sucker Rod Centralizer / Oil Tubing Centralizer for sale
